SRP Formula-R Edition
SRP

SRP Formula-R Edition

$909.00
Tax calculated at checkout

Build Your SRP Formula-R Edition

Choose your finish, pedal color, and add-ons. Selected paid options will be added to cart as matching Shopify products.

Step 1

Choose Finish

Your finish determines the main pedal set and matching hardware variants.

Step 2

Choose Pedal Color

Choose your pedal color. Default/included color is free; paid colors will be added as a separate line item.

Optional Core Pedal Setup

Choose the major pedal configuration components.

Optional Ergonomics

Dial in the pedal shape

Optional Feedback

Add vibration or feedback components.

Final Setup

Pedal Position

Choose the factory pre-assembly position for your pedals.

Build Summary

Estimated total --
Your configuration will be attached to the main product. Selected paid options will be added to cart as individual Shopify products.
Availability In stock
WarrantyFull Manufacturer Warranty
Returns30 days
Ships direct from SRP in Spain, usually within a few business days. Flat $50 US shipping ($110 on orders over $500), shown at checkout.
⚠️ Heads-up: US import duty of roughly 10% applies on top of your order total and is billed separately — it is not included in the price at checkout.
Tested and supported by our team in the US
contact: (904) 606-5888
Amazon American Express Apple Pay Diners ClubDiscoverGoogle Pay Mastercard PayPalShop Pay Visa
SRP Formula-R Edition
Free shipping over $150 · ships in 1 business day
$909.00
Single-seater geometry

A monocoque frame with the stiffness and ultra-short travel of a real open-wheel car — the pressure response is immediate.

Same brake as the GT-R

R-Piston V5 pneumatic braking: air instead of elastomer, so your reference point on lap 40 is the one from lap 3.

Quick-release stroke

Set 15–45 mm of brake travel without tools, and shape the curve digitally in MySETUP PRO mode.

Built like a machine part

5-axis CNC AL6061, 28-micron hard anodizing, SKF needle bearings on every pivot.

Specifications

Type2-pedal open-wheel pneumatic pedal set (throttle + brake); clutch available as add-on
Brake systemR-PISTON V5 pneumatic — sealed industrial cylinder, stainless piston, NBR seals
Brake travel15–45 mm, quick-release adjustment
GeometryMonocoque single-seater frame — ultra-short travel, immediate pressure response
Resolution16-bit (65,536 steps), ceramic transducers — zero thermal fade
Construction100% AL6061 aluminum, 5-axis CNC machined, 28-micron hard anodized
BearingsSKF needle bearings on every pivot
ConnectionUSB-C · USB 2.0/3.0 · PC native · PlayStation/Xbox via DriveHub (third-party)
SoftwareSRP MySETUP with PRO mode, custom curves, multi-formula profiles, real-time brake bias
Best forFormula 1, FIA F2, prototypes, Super Formula
RequirementRigid professional cockpit — not suitable for wheel stands with flex
ColoursGray · Black
Warranty2-year full warranty
Ships fromSRP, Blanes (Spain) — see shipping & duty below

FAQ

Formula-R or GT-R?
Same R-Piston pneumatic brake in both. The Formula-R is a monocoque open-wheel frame with ultra-short travel for F1, F2 and prototype driving. The GT-R is the multi-discipline frame (GT3, rally, endurance) with the brake travel regulator and monocoque baseplate as standard. If you drive both kinds of car, the GT-R is the safer pick; text Jon at (904) 606-5888 if you're between them.
Does it need a rigid cockpit?
Yes — mandatory. The pneumatic forces will flex a wheel stand. 80/20 profile rigs and Sim-Lab, Trak Racer, GT Omega and ASR cockpits are all fine.
Two pedals or three?
The Formula-R ships as throttle + brake. For a clutch, add the SRP Clutch Kit at checkout; SRP pairs it with GT-R colour keys for the Formula-R.
What will shipping and import duty actually cost me?
Shipping is a flat $50 (or $110 on orders over $500) and is shown at checkout. Because the pedals ship from Spain, US import duty of roughly 10% applies on top of your order total and is billed separately — it is not included in the checkout price, so budget for it.
Does it work on PlayStation or Xbox?
Natively it's PC. Console use works through a third-party DriveHub adapter, which SRP doesn't supply.

In the box

  • Formula-R throttle pedal
  • Formula-R pneumatic brake pedal
  • Mounting hardware
  • USB-C cable
